| Number of Power Amps |
7 |
| Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive) |
80 W |
| Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) |
120 W |
| Power Output (6 ohm, 1 kHz, 1% 1ch Drive) |
145 W |
| Speaker impedance |
4-16Ω/ohms |
| Input sensitivity |
200 mV |
| Frequency response |
10 Hz - 100 kHz — +1, –3 dB (Direct mode) |
| S/N Ratio |
98dB (IHF-A weighted, Direct mode) |
| FM section (Tuning frequency range) |
87.5 - 107.9 MHz |
| AM section (Tuning frequency range) |
520 - 1710 kHz |
| Power Supply |
AC 230 V, 50 Hz |
| Power Consumption in W |
440 |
| Power Consumption No-Sound (ECO On / Off) in W |
29 W / 39 W |
| Weight in kg |
8.6 |
| 3.5mm audio line-in connection |
Yes |
| System Remote Control |
RC-1244 |
| Standby Consumption in W |
0.1 |
| CEC Standby Consumption in W |
0.5 |
| Carton Maximum Dimensions (W x D x H) in mm |
523 x 435 x 232 |
| Carton Weight (inc. product) in kg |
10.6 |
| Colour |
Black |
| Maximum Dimensions (W x D x H) in mm |
434 x 339 x 151 mm |
| Maximum Dimensions - Antenna:Horizontal:(W x D x H) in mm |
434 x 339 x 215 mm |
| HDMI In / Out |
6 / 1 |
| Composite In / Out |
2 / 1 |
| Phono (MM) In |
Yes |
| Analogue In/Out |
2 / No |
| Digital Optical In/Out |
2 / No |
| Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB |
No / No / No / No / Yes |
| Pre-out / Main-in |
0.2 ch / No |
| Multi-Room Speaker Terminal |
assignable |
| Headphone Output |
Yes |
| Ethernet |
Yes |
| AM/FM Tuner |
Yes |
| USB Audio / Made for iPod / Made for iPhone |
Yes / AirPlay / AirPlay |
| Bi-amp Drive |
assignable |
| Speaker A / B |
assignable |
| Number of Speaker Terminals |
7 |
| Subwoofer Out |
2 |
| Multichannel Preout |
Yes (0.2) |
| Digital Outputs: Coaxial / Optical |
2 / 0 |
| Digital Coaxial In / Out |
2 / 0 |
| DAB / DAB+ tuner |
No |
| FM Tuner with RDS |
Yes |
| Max Number of Processing (Preamp) Channels |
7.1 |
| DTS HD Master / DTS:X |
Yes / Yes |
| DTS Neo:X / DTS Neural:X |
No / Yes |
| DTS Virtual:X |
Yes |
| Dolby TrueHD / Dolby Atmos |
Yes / Yes |
| Dolby ProLogic Ilz / Dolby Surround |
No / Yes |
| Dolby Height Virtualisation |
Yes |
| Multichannel Stereo |
Yes |
| Dialogue Enhancer |
Yes |
| Discrete Power Amplifiers |
7 |
| Audyssey Dynamic EQ / Dynamic Volume |
Yes / Yes |
| Speaker Setup Presets |
2 |
| Audyssey |
MultEQ XT |
| Audyssey APP Support |
Yes |
| Compressed Audio Restorer |
Yes |
| Gapless playback |
Yes (FLAC, WAV, ALAC, DSD) |
| Internet Radio |
TuneIn |
| Compatible with Remote APP for Smart Phones |
Android / iOS |
| Compatible with Remote APP for Tablets |
Android / iOS / Amazon Kindle |
| HEOS Multiroom and Streaming |
Yes |
| Lossy Formats: MP3 / WMA / AAC |
Yes / Yes / Yes |
| Lossless Formats: FLAC / ALAC / WAV |
Yes / Yes / Yes |
| DSD Audio Streaming |
up to DSD5.6 |
| FLAC HD 192/24 |
Yes |
| WAV 192/24 |
Yes |
| ALAC 192/24 |
Yes |
| AirPlay 2 |
Yes |
| Roon Tested |
Yes |
| Spotify Connect* / Tidal* / Deezer* / others * |
Yes / Yes / Yes / Yes |
| Amazon Prime Music* / Pandora* |
Yes / Yes |
| Ethernet Ports |
Yes |
| Wi-Fi |
Yes |
| Bluetooth |
Yes |
| Bluetooth Headphone transmission |
Yes |
| HDMI Inputs: Back / Front |
6 (3x 8K) / 0 |
| HDMI max Resolution (8k / 4k) |
8k/60 - 4k/120 |
| HDMI Outputs: Main / Zone |
1 / - |
| HDMI to HDMI Scaling |
up to 8K 60/50 |
| HDCP2.3 support |
Yes |
| HDMI: 8K / 4K / CEC / eARC |
Yes / Yes / Yes / Yes |
| HDMI: Dolby Vision / HDR 10+ / Dynamic HDR / HLG |
Yes / Yes / Yes / Yes |
| HDMI: ALLM / QMS / QFT / VRR |
Yes / Yes / Yes / Yes |
| HDMI pass-though in standby mode |
Yes |
| Multiroom zones |
2 |
| Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analogue |
Yes (2ch) / Yes (2ch) / Yes / Yes |
| HEOS Multiroom integrated |
Yes |
| TV Sound grouping |
Yes |
| Main room multichanel audio - Zone stereo downmix |
Yes |
| Zone Audio Output: Speaker / Preout |
Yes / No |
| Webbrowser User Interface |
Yes |
| IP Control / RS232 Control / Web Control / App Control |
Yes / No / Yes / Yes |
| Auto Speaker Setup by Microphone |
Audyssey MultEQ XT |
| FL Display |
1 line |
| Graphic User Interface - GUI |
Hybrid GUI |
| GUI Languages |
9 |
| Voice Control - Works with Amazon Alexa |
Yes |
| Voice Control - Google Assist / Apple Siri |
Yes |
| Setup Assistant |
Yes |
| Quick Select Plus / Quick Select |
Yes / No |
| Firmware Update by: Network / USB |
Yes / Yes |
| Variable Cross Over |
Yes |
| Optimised Bass Redirection |
Yes |
| ECO Mode |
Yes |
| Auto Power Off |
Yes |
| Sleep Timer |
Yes |
