| Panel |
|
|---|
| Type |
IPS |
|---|
| Backlight |
LED |
|---|
| Size |
27" / 68.5 cm |
|---|
| Native Resolution |
2560 x 1440 (16:9 aspect ratio) |
|---|
| Viewable Image Size (H x V) |
596.7 x 335.7 mm |
|---|
| Pixel Pitch |
0.233 x 0.233 mm |
|---|
| Pixel Density |
109 ppi |
|---|
| Display Colors |
16.77 million |
|---|
| Viewing Angles (H / V, typical) |
178° / 178° |
|---|
| Brightness (typical) |
350 cd/m2 |
|---|
| Contrast Ratio (typical) |
1000:1 |
|---|
| Response Time (typical) |
5 ms (gray-to-gray) |
|---|
| Color Gamut (typical) |
sRGB |
|---|
| Video Signals |
|
|---|
| Input Terminals |
DisplayPort (HDCP 1.3) x 2, HDMI (HDCP 1.4), DVI-D (HDCP 1.4) |
|---|
| Digital Scanning Frequency (H / V) |
DisplayPort: 31 - 89 kHz / 59 - 61 Hz
HDMI: 31 - 89 kHz / 29 - 31 Hz, 49 - 51 Hz, 59 - 61 Hz
DVI: 31 - 89 kHz / 29 - 31 Hz, 59 - 61 Hz |
|---|
| USB |
|
|---|
| Upstream |
USB 3.1 Gen 1: Type-B |
|---|
| Downstream |
USB 3.1 Gen 1: Type-A x 4 |
|---|
| Audio |
|
|---|
| Speakers |
1.0 W + 1.0 W |
|---|
| Input Terminals |
Stereo mini jack, DisplayPort x 2, HDMI |
|---|
| Output Terminals |
Headphones (Stereo mini jack) |
|---|
| Power |
|
|---|
| Power Requirements |
AC 100 - 240 V, 50 / 60 Hz |
|---|
| Typical Power Consumption |
16 W |
|---|
| Maximum Power Consumption |
67 W |
|---|
| Power Save Mode |
0.5 W or less |
|---|
| Features & Functions |
|
|---|
| Preset Modes |
User1, User2, sRGB, Paper, Movie, DICOM |
|---|
| Auto EcoView |
Yes |
|---|
| OSD Languages |
English, German, French, Italian, Japanese, Simplified Chinese, Spanish, Swedish, Traditional Chinese |
|---|
| Physical Specifications |
|
|---|
| Dimensions (Landscape, W x H x D) |
611.7 x 376.3 - 545.3 x 230 mm |
|---|
| Dimensions (Without Stand, W x H x D) |
611.7 x 364.4 x 53.7 mm |
|---|
| Net Weight |
8.5 kg |
|---|
| Net Weight (Without Stand) |
5.7 kg |
|---|
| Height Adjustment Range |
169 mm |
|---|
| Tilt |
35° Up, 5° Down |
|---|
| Swivel |
344° |
|---|
| Pivot |
90° (both clockwise and counter clockwise) |
|---|
| Hole Spacing (VESA Standard) |
100 x 100 mm |
|---|
| Environmental Requirements |
|
|---|
| Operating Temperature |
5 - 35°C |
|---|
| Operating Humidity (R.H., non condensing) |
20 - 80% |
|---|
| Certifications & Standards (Please contact EIZO for the latest information.) |
TCO Certified Generation 8, EPEAT 2018 (US), TUV/Ergonomics, TUV/Low blue light content, TUV/Flicker Free, TUV/GS, RCM, CE, CB, cTUVus, FCC-B, CAN ICES-3 (B), TUV/S, PSE, VCCI-B, EPA Energy Star, RoHS, WEEE, China RoHS, CCC, China Energy Label Grade2, EAC |
|---|
| Dedicated Software |
|
|---|
| Monitor Control Utility Screen InStyle |
Supported |
|---|
| Supplied Accessories (May vary by country. Please contact EIZO for details.) |
|
|---|
| Signal Cables |
DisplayPort (2 m) |
|---|
| Others |
AC power cord (2 m), USB Type-A - USB Type-B cable (2 m), VESA mounting screw x 4, setup guide |
|---|
| Warranty |
Five Years |
|---|
