SPECIFICATIONS
INTEGRATED NETWORK STREAMER
S14
All specifications are accurate at the time of printing.
Rotel reserves the right to make improvements without notice.
Use of the Works with Apple badge means that an accessory has been designed to work
specifically with the technology identified in the badge and has been certified by the
developer to meet Apple performance standards.
To control this AirPlay 2–enabled speaker, iOS 11.4 or later is required.
Apple, AirPlay, Apple TV, Apple Watch, iPad, iPad Air, iPad Pro, iPhone, and Lightning are
trademarks of Apple Inc., registered in the U.S. and other countries.
Maximum Power Output 150 watts/ch (4 ohms)
Continuous Power Output 80 watts/ch (8 ohms)
Total Harmonic Distortion < 0.04%
Intermodulation Distortion < 0.03%
(60 Hz : 7kHz, 4:1)
Frequency Response
Line Level Inputs 10 Hz - 100k Hz, 0 ± 0.5 dB
Damping Factor 400
(20 Hz - 20 kHz, 8 ohms)
Input Sensitivity / Impedance
Line Level Inputs 200 mV / 47k ohms
Input Overload
Line Level Inputs 4.5 V
Tone Controls - Bass / Treble ± 10 dB at 100 Hz / 10k Hz
Signal to Noise Ratio (IHF A-weighted)
Line Level Inputs 100 dB
Digital to Analog Converters ESS
Digital Section
Frequency Response 10 Hz - 90k Hz (0 ± 2 dB, Max)
Signal to Noise Ratio (IHF A-weighted) 98 dB
Input Sensitivity/Impedance -20 dBfs / 75 ohms
Digital Inputs SPDIF LPCM
(up to 24-bit / 192k Hz)
PC-USB USB Audio Class 2.0
(up to 24-bit / 384k Hz )*
*Driver installation required
Support MQA and MQA Studio
(up to 24-bit / 384k Hz )
