| PERFORMANCE |
| Processor |
Intel® Core Ultra 9 285T, 24C (8P + 16E) / 24T, Max Turbo up to 5.4GHz, 36MB Intel Smart Cache
|
| AI PC Category
|
AI-Ready Workstations
|
| Processor Sockets |
1x FCLGA1851
|
| Integrated Graphics |
Integrated Intel® Graphics
|
| Discrete Graphics |
1x NVIDIA® RTX A1000 8GB
|
| Chipset |
Intel® Q870 Chipset
|
| Memory |
2x 32GB SODIMM DDR5-5600 Non-ECC
|
| Memory Slots |
Two DDR5 SODIMM slots, dual-channel capable
|
| Max Memory
|
Up to 128GB (2x 64GB DDR5 CSODIMM)
|
| PCIe NVMe Controller |
Integrated NVMe® controller
|
| PCIe NVMe Drive |
2x 1TB SSD M.2 2280 PCIe® 4.0x4 Performance NVMe® Opal
|
| Audio Chip |
High Definition (HD) Audio, Realtek® ALC233VB codec
|
| Power Supply |
170W 89% Adapter
|
| DESIGN |
| Keyboard |
USB, Calliope, Black, Hebrew
|
| Mouse |
USB Calliope Mouse, Black
|
| Case Color |
Black
|
| Dust Filter |
None
|
| Toolless Chassis Screw |
Toolless Chassis Screw
|
| Mounting |
None
|
| Stand |
None
|
| Dimensions (WxDxH)
|
179 x 182.9 x 37mm with rubber feet (7.0 x 7.2 x 1.5 inches with rubber feet)
|
| Weight
|
1.4 kg (3 lbs, maximum configuration)
|
| CONNECTIVITY |
| Onboard Ethernet |
Intel® I219-LM, 1x GbE RJ-45
|
| Optional Ethernet |
None
|
| WLAN + Bluetooth |
Intel® Wi-Fi® 7 BE200, 802.11be 2x2 + BT5.4, vPro®
|
| Front Ports |
- 1x USB-C® (USB 20Gbps / USB 3.2 Gen 2x2), data transfer only
- 1x USB-A (USB 10Gbps / USB 3.2 Gen 2), Always On
- 1x USB-A (USB 10Gbps / USB 3.2 Gen 2)
- 1x headphone / microphone combo jack (3.5mm)
|
| Rear Ports |
- 1x USB-A (USB 5Gbps / USB 3.2 Gen 1)
- 3x USB-A (USB 10Gbps / USB 3.2 Gen 2), one supports Smart Power On
- 1x HDMI® 2.1 TMDS
- 1x DisplayPort™ 1.4
- 1x Ethernet (GbE RJ-45)
|
| Optional Rear Ports (configured) |
4x miniDP 1.4a on NVIDIA® RTX A1000
|
| SECURITY & PRIVACY |
| Security Chip |
Discrete TPM 2.0, TCG certified, FIPS 140-2 certified
|
| Physical Locks |
Kensington® Security Slot™, 3 x 7 mm
|
| Cable Lock |
No Cable
|
| Chassis Intrusion Switch |
Chassis Intrusion Switch
|
| MANAGEABILITY |
| System Management |
Intel® vPro® Enterprise with Intel AMT 16
|
| SERVICE |
| Base Warranty |
3-year, Onsite
|
| Included Upgrade |
1Y Premier Support from 3Y Onsite Windchill bundles (CPN)
|
| CERTIFICATIONS |
| ISV Certifications |
Please visit ISV certifications for Lenovo® Workstations
|
| Mil-Spec Test |
MIL-STD-810H military test passed
|
| SOFTWARE |
| Operating System |
Windows® 11 Pro, Hebrew / English
|
